The fire damper blade roll forming machine is a specialized production line designed to manufacture various shapes of damper blades with or without slotted holes. These blades are used in fire assurance products, particularly in heating, ventilation, and air conditioning (HVAC) systems, to prevent the spread of fire and smoke through ducts and pipes. This machine is a cost-effective and efficient solution for mass production of fire damper blades, offering numerous benefits and features that enhance its performance and reliability.
Key Features and Specifications
The fire damper roll forming machine is a complete production line that includes several key components:
- Decoiler: The machine starts with a decoiler that unwinds the coil material, which is typically made of galvanized steel with a thickness range of 0.7-1.5 mm.
- Guide and Leveling Rollers: These rollers ensure the material is properly aligned and leveled throughout the manufacturing process.
- Main Fire Damper Blade Roll Former: This is the core component of the machine, responsible for forming the damper blades into various shapes and profiles.
- Hydraulic Cutting Device: The machine includes a hydraulic cutting device that cuts the formed blades to the desired length.
- PLC Control System: The machine is controlled by a programmable logic controller (PLC) that ensures precise and automated operation.
- Run Out Table: The finished blades are stacked on a run out table, which provides a stable and secure surface for the products.
Machine Components and Specifications
The fire damper blade roll forming machine includes several key components with specific specifications:
Decoiler: 1 set, passive or hydraulic, with a weight capacity of 3 tons.
Guide and Leveling Rollers: 1 set.
Main Fire Damper Blade Roll Former: 1 set, with 8-10 forming stations depending on the profile, and a forming speed of 5-12 m/min.
Hydraulic Cutting Device: 1 set, with a cutting die material of Cr12Mov and a cutting tolerance of +/- 1 mm (10 m).
Run Out Table: 2 sets, with a table type of no power passive with rollers.
Benefits and Uses
The fire damper blade roll forming machine offers several benefits and uses:
- High Productivity: The machine can produce a large volume of fire damper blades quickly and efficiently, reducing labor costs and increasing production capacity.
- Precision and Accuracy: The machine's PLC control system ensures precise and automated operation, resulting in high-quality products with minimal defects.
- Cost-Effective: The machine is designed to be cost-effective, with a lower initial investment and reduced maintenance costs compared to manual production methods.
- Versatility: The machine can produce various shapes and profiles of damper blades, making it suitable for different applications and industries.
- Fire Safety: Fire dampers are critical components in fire safety systems, and the machine ensures the production of high-quality blades that meet fire safety standards.
Brand Name: Jugmug RollForming
Jugmug RollForming is a well-known brand in the roll forming industry, offering a range of machines and solutions for various applications. Their fire damper blade roll forming machine is designed to provide high-quality products with precision and accuracy, ensuring the safety and efficiency of fire safety systems.
Conclusion
The fire damper blade roll forming machine is a specialized production line designed to manufacture high-quality damper blades for fire safety applications. With its advanced features and specifications, the machine offers numerous benefits, including high productivity, precision, and cost-effectiveness. Jugmug RollForming is a reputable brand in the industry, providing reliable and efficient solutions for fire damper blade production.
